Available tools for hire

The ERJ170/190-946 kit contains all test adaptors and hoses required to connect the Air Data Test Set (ADTS – GSE144) to the Air Data System Probes (ADSP) of the aircraft for the performance of tests on the main and standby air data systems of the ERJ 170 and 190 aircraft, as per the relevant Embraer Aircraft Maintenance Manual (Maintenance Practices).

This ERJ170/190–946 kit also contains all test adaptors and hoses required to perform an air data test to:

• Reduced Vertical Separation Rules (RVSM) Standards
• Cabin Differential Pressure Valve
• Cabin Pressure Altimetric Module (CPAM)

Included in this kit

• Test Adaptor for ADSP Part No. APA97632M1-3-4-4 (4 req’d)
• Pre-Test Probe for ADSP P/N PT421-632 (4 req’d)
• Pitot Test Hose Assembly PT Part No. ERJ-PT RVSM (1 req’d)
• Static Test Hose Assembly PS1/PS3 Part No. ERJ-PS1/3 RVSM (1 req’d)
• Static Test Hose Assembly PS2 Part No. ERJ-PS2 RVSM (1 req’d)
• Static Test Adaptor – Cabin Differential Pressure Valve Static Port Part No. S34146-4 (1 req’d)
• Test Hose – Static Port Cabin Differential Pressure Valve Part No. ERJ-CDP (1 req’d)
• Cabin Pressure Altimetric Module (CPAM) – Test Hose and Module Connector Assembly Part No. CPAM-532 (1 req’d)
• Seal Kit for ADSP Test Adaptor Part No. SK7632 (2 req’d)
• Seal for Cabin Differential Pressure Valve – Static Port Test Adaptor Seal – Part No. S341-61 (1 req’d)
• Hose Suspension Arm Part No. 532-8971DB (4req’d)
• Lubricating Fluid Part No. LF5050 (1 req’d)
• Carrying Case Part No. 129XD-ERJ170/190-946 (1 req’d)
